CNC 5 axis Processing Center Router Machine

The Recoji (Our own designed machines )Series 5 Axis CNC Processing Center Router Machine is a profesional stable good quality multi axis cnc 5 axis router, it is ready for production cutting, drilling, trimming, as well as prototype-and fixture-machining in a large work envelope, accessible from all angles. High class 5 aixs is a very high price machine, but now you will have a good price for this kind of machines, we are sure this can help you create more.If you want to buy, please write to us: Company sales email：2832357617@qq.com

webwxgetmsgimg (2).jpg

webwxgetmsgimg (4).jpg

webwxgetmsgimg (3).jpg

Because of the high price for 5 axis system, we choose wordwide good brand system for this machine, 5 axis moving Axis. Supply the post, customers will be easy to update, we have suitable high price version, but if customers can do all by yourself, this is a good machine to run.

Series	RECOJI2500
Travelling Size	286035601000mm
Working Size	25003000850mm
Table size	3250*5250mm
Transmission	X/Y rack and pinion drive,Z ball screw drive, A and B axis with robot gears
A and B axis moving range	A and B: -120 degree to +120 degress
Motion Parts	All axes with linear guides
Table structure	Aluninum T slot table
Spindle Power	3.7;5.5;9KW (Option: customized by customers) Italy INTEGRATED 5axis head
Spindle speed	24000 r/min
Travelling Speed	60m/min
Working speed	35m/min
Tool	ER
Driving system	Japanese AC servo
Voltage	AC380V/3PH/50HZ (Option: customized by customers)
Controller	Syntec 5axis system with RTCP

webwxgetmsgimg (1).jpg

Company sales email：2832357617@qq.com
